Accueil concentrateur et pompe à oxygène Pompe à vide à moteur à aimant permanent de taille mini légère pompe à concentrateur d'oxygène Portable sans huile DC 12V

Pompe à vide à moteur à aimant permanent de taille mini légère pompe à concentrateur d'oxygène Portable sans huile DC 12V

Compresseur d'air sans huile développé indépendamment par la société VU pour le concentrateur d'oxygène portable

  • Les détails du produit

Pompe à vide à moteur à aimant permanent de taille mini légère pompe à concentrateur d'oxygène Portable sans huile DC 12V

Compresseur d'air sans huile développé indépendamment par Weiyou Intelligent Technology Co.Ltd. pour le concentrateur d'oxygène portable. Le compresseur d'air a adopté une pompe à piston oscillant avec une structure à double cylindre, des coupelles en cuir importées et des roulements à billes haute performance pour assurer sa longue durée de vie et est complètement sans huile et sans entretien. Il est particulièrement adapté pour une utilisation dans des conditions de structure compacte, de poids léger et de joint de piston haute performance.


1. APPLICATIONS TYPIQUES

(1) concentrateur d'oxygène portable ;

(2)Petit équipement d'analyse ;

(3)Instrumentation ;

(4) parfum ambiant ;

(5)Automatisation de laboratoire ;




 DONNÉES DE PERFORMANCE (le moteur doit être entraîné par le contrôleur)

Entrée de tension nominale

12V CC

Max. flux d'air ouvert

0,5 cfm (14,1 L/min)

Pression nominale

20PSI (1.4bar)

Courant nominal

4.8A +/-10%

Puissance nominale

58W +/-10%

Max. pression

30PSI (2.1bar)

Type de moteur

CC sans balais à 8 pôles, triphasé

Classe d'isolation du moteur

155°

Protection moteur

Non inclus - Client à intégrer dans le contrôleur de système

Température ambiante de fonctionnement

50° À 104° F (10~40°C)

Poids net

0,88 lb (0,4 kg)

Câble d'alimentation, calibre



Fil de capteur à effet Hall, manomètre
